Router Spline Jig Plan
This digital plan accompanies my Router Spline Jig build video and provides additional details and reference information about the jig I built and use in my workshop.
The jig is designed for cutting decorative splines in mitered boxes using a router table. The PDF documents my own build and setup, including the materials, hardware, component dimensions, assembly details and the way I position and use the jig on my router table.
Reference drawings are provided with metric dimensions and approximate imperial equivalents, making it easy to follow the dimensions used in my build.
The download also includes full-size DXF files for the laser/CNC-cut components. These files are provided at 1:1 scale in millimeters and can be imported into compatible CAD/CAM or laser software.
Included in the download:
- Detailed PDF build document
- Dimensions and reference drawings
- Materials and hardware list
- Assembly details
- Router table setup
- Full-size DXF cutting files (1:1, mm)
- Link to the complete build video
This plan is intended to complement the build video, where you can see the complete process and how I use the jig in my workshop.
Digital product only. No physical product will be shipped.
